IEC 63252:2020 pdf download - Energy consumption of vending machines

IEC 63252 defines methods for the measurement of energy consumption of vending machines,whether or not fitted with refrigerating appliances.

5.2 Equipment location for test

Figure B.1 shows the position of the machine in the test room.

The machine is to be installed so that the rearmost part of the cabinet is at a minimum of100 mm from any vertical surface at the rear of the machine.

There shall be a minimum of 1 m between the side or front of the machine casing and any

vertical surface at the side or front of the machine.

There shall be a minimum of 250 mm between the top of the machine and the ceiling of the test room.

5.3 Energy consumption and recording

The energy consumption shall be measured by a direct meter reading method,as described in EN 50564 and recorded in the test report shown in Annex B.
